UNIQUE COMBUSTION
The GranView incorporates unique combustion air supply system that directs outside air to every supply port inside the fire chamber. By directly connecting the combustion air from outside the home to the unt, heated room air is nt lost up the chimney when you are burning fire. “Fireplace odor” or cold drafts will never invade your home whenthe fireplace is nt in use. A specially designed air wash provides ample flow of incoming air to continually sweep the glass clean and create dramatic flame pattern.
SPECIFICATIONS
- Framing Dimensions:45-1/2” wide x 51” high x 24” deep
- Chimney Size:8” Diameter
- Weight:685 lbs.
- Firewood Lenth:24” average
- Firebox Size:4.2 cubic ft.
- Convection Air Circulation of 200 CU. FT./ Minte, Bowers optional
- Optional Heat Ducting Met /strong>
- Overall efficiency:72%
- Emissions:2.72g/kg
- Complies with EPA requirements as a fireplace
ZERO CLEARANCE IntALLATION
The zero clearance surround provides easy, cost effective intallation. A special foundation or support is nt required to intall the fireplace. 95.4% Combustion Efficient Design While you’re relaxing inthe warmth of the fire, the GranView is hard at work burning the smoke that is wasted by normal fireplace designs. This clean burning fireplace limits hydrocarbon emissions, reducing creosote accumulation inthe chimney.
FLEXIBLE DESIGN OPTIONS
The elegant style of our arched or rectangular doors can be enhanced with optional nickel plating or an ancient iron distressed steel look to create a fireplace design with unlimited decorating options. Choose the look you desire by finishing your intallation with stone, tile, stucco or any manufactured facing material to create the fireplace of your dreams.
Additional information
| Brand | Wilkening Fireplace |
|---|---|
| Product Type | Fireplace |
| Fuel Type | Wood |
| Design Style | Traditional |
